Drive2 PTV

Description

Drive² PTV SPECIFICATIONS

ENGINE/DRIVETRAIN

• Fuel System: EFI – Electronic Fuel Injection
• ENGINE TYPE: Yamaha-built, 357 cc, low-emission single cylinder 60° incline OHV
• LUBRICATION SYSTEM: Splash-style positive oil lubrication
• OIL CAPACITY: 1 U.S. quart (1 liter, 1,000 cc)
• AIR CLEANER: Two-stage, urethane-foam pre-cleaner, and high-capacity pleated paper cartridge
• COOLING SYSTEM: Forced Cooling
• STARTING SYSTEM: Starter generator with pedal start system

GENERAL

• Dry Weight: QuieTech EFI: 751 lb (341kg), PowerTech AC: 665.8 lb (302 kb)
• Curb Weight: QuieTech EFI: 785 lb (356 kg), PowerTech AC: 1063 lb (482 kb) PowerTech Li: 1063 lb (805.3 kb)
• Tire Size: 205/65-10 DOT (4 ply rating)
• Seating Capacity: 2 persons
• Available Model Colors: In-Mold: Glacier; Matte: Titan, Arctic Drift; Metallic: Carbon, Coral Red, Onyx, Peridot, Pearl
• Available Seat Color: Standard: Stone Optional: Black
• Available Suntop Color: Standard: Stone Optional: Black

DIMENSIONS

• Overall Length: 93.6 in (238 cm)
• Overall Width: 47.3 in (120 cm)
• Overall Height(with suntop): 70.2 in (178 cm)
• Wheelbase: 64.4 in (164 cm)
• Front Wheel Tread: 35 in (89 cm)
• Rear Wheel Tread: 38.7 in (98 cm)
• Floor Board Height: 12.9 in (33 cm)

CHASSIS

• FRAME: HybriCore™ Chassis features a robotic welded automotive ladder-style steel frame protected with a multi-step full-immersion phosphate treatment, electrodeposition epoxy-based coating, and an electrostatic applied polyester/urethane powder topcoat.
• STEERING: Self-compensating double reduction helical rack-and-pinion.
• FRONT WHEEL SUSPENSION: Tru-Trak II™ fully independent automotive-style strut suspension.
• REAR WHEEL SUSPENSION: Fully independent automotive-style strut suspension.
• BRAKES: Self-adjusting mechanical, rear wheel drum brakes.
• BUMPERS Front and rear 5 mph energy-absorbing bumpers.

PERFORMANCE

• Maximum Forward Speed: 19.0 mph (31 km/h)
• Minimum turning radius: 9.5 ft (2.9 m)
